ElvaX Plus
New standard of XRF
ElvaX Plus analyzer is a benchtop energy-dispersive X-ray fluorescence (EDXRF) spectrometer with extended element range from Na (Z=11) to U (Z=92). The Helium purge system and the automatic primary filter changer and the large area SDD detector allow to register effectively characteristic lines of chemical elements. ElvaX Plus analyser is used for quantitative and qualitative analysis of chemical composition of different alloys, minerals, liquids, powders, food, car catalysts and biological substances, as well as elements deposited on surfaces or filters, in a wide range of element concentrations (from Mg (12) to Pu (94). LOD (liimits of detection) of the analyser demonstrate better than 1 ppm for most elements even in a light matrix.
- The fastest XRF spectrometer in the World (intensity with more than 400 000 cps) – the excellent precision and accuracy and limits of detection within short duration of the measurement time
- Wide range of element detection from Na (Z=11) to U (Z=92)
- Helium purge option significantly improves limits of detection of light elements (Na, Mg, Al, Si, P, S)
- Perfect stability of calibration, compensation of out of range temperature and pressure adjustments
- Optional 16-position automatic sample changer improves productivity of spectrometer
- Optional high-resolution CCD camera for precise positioning of samples
- Affordable and does not require expensive maintenance, service and consumables
ElvaX Plus is a user-friendly and advanced spectrometer for fast chemical analysis on a daily basis for a wide range of applications.
ElvaX Plus with an advanced analytical software toolkit and user-friendly interface, allow any operator to make any necessary analysis in seconds or minutes (if needed).
Digital X-Ray Source digiX-50
Anode: W, Rh, Ag
Voltage: 50 kV
Power: 5 W
5 position filter changer
X-Ray Detector
Type: Fast SDD
Area: 25 mm2
Energy resolution: 140 eV at Mn Kα, 85 eV at Al Kα
Count rate: 500 000 cps
Electronics
DPP: proprietory DAS (Dynamically Adaptive Shaping) type, 80 MHz sampling rate
MCA: 4096 channels
General
Dimensions: 430 х 340 х 200 mm
Weight: 18 kg
Power supply: 90 – 240 V, 50/60 Hz
Power consumption: 40 W
Software
Operating system: Windows XP/Vista/7/8/10
Analysis algorithms: Fundamental parameters (FPA), Empirical (regression) calibrations, Manual spectra comparison
Related Products
Rotary Rock Sampler
The Rotary Rock Sampler is designed to produce consistent, representative samples from crushed rocks, minerals and other inert, dry materials. Its controlled rotary motion and metered feed help reduce sampling bias and human error, making it ideal for XRF/XRD and geochemical analysis. Compact and durable, it can be used both in the field and in the laboratory, with easy cleaning between batches to prevent cross-contamination.
Portable Beater Mill
Portable Beater Mill designed for on-site sample preparation. Suitable for rapid grinding of rocks, minerals and other inert, dry materials. Delivers consistent particle size for further laboratory analysis (XRF/XRD, assay, geochemical testing). Not intended for organic, wet or flammable materials. Rugged, easy to transport, ideal for fieldwork and small laboratories.
Field Portable 4Ton Pellet Press
The field portable press is designed to allow proper light element analysis for soil and rock samples in the field.
SQM-0.4L Planetary Ball Mill
SQM-0.4L oil-sealed planetary ball mill is an essential device for mixing, fine grinding, sample preparation, nano-material dispersion, new product development and small batch production of high-tech materials.
Accuracy
Advanced hardware and patented powerful software algorithms allow the ElvaX Plus to demonstrate the highest precision and accuracy of chemical elements analysis for a various substances and materials.
Speed
Related Products
Dynamically Adaptive Shaping (DAS) DPP designed by Elvatech specialists and the Fast SDD detector allow ElvaX Plus to be the fastest XRF spectrometer on this segment.
Stability
Due to the digiX-50 digital X-Ray tube, automatic correction of temperature and pressure, and automatic drift correction, ElvaX Plus possess long-term reproducibility of the analysis without the need to make re-calibration of the spectrometer manually.
